the smallest China ECB100 3 Axis Compass from manufacturer, provides accurate heading and tilt readings, easy to be integrated, widely used in antenna pointing, buoy, laser rangefinders, etc.
Smallest Size: 16.5*16.5*6.5mm
3D Angle (Heading, Pitch, Roll) Output
Heading Accuracy: 0.8° RMS (25°C, Tilt Angle<30°)
Pitch and Roll Accuracy: ±0.1° (25°C, Full Range)
Hard/Soft Magnetic Compensation, Tilt Compensation
China ECB100 3 axis compass is the smallest compass module that provides accurate heading and tilt readings, SkyMEMS’s advanced hard and soft iron correction algorithms allow for compensation of magnetic distortions inherent in the user’s system, resulting in reliable and consistent readings.
ECB100 3 axis compass from China factory integrates 3-axis magneto-inductive sensors, 3-axis MEMS accelerometer and central processing unit to calculate the heading data in real time and compensate the heading when it has inclination angle. The small size and low power consumption make ECB100 suitable for size sensitive measurement systems. ECB100 is the best choice for applications that require high performance, ultra-small size and low cost, it has been widely used in laser rangefinders, antenna positioning, buoy, unmanned systems and marine navigation fields, etc.
ECB100 3 axis compass from China factory is a small board-based electronic compass sensor, it is a low-cost compass that provides accurate heading and tilt angles, it has been widely applied in the following fields:
– Laser Range Finder
– Antenna Positioning
– Buoy
– Drones and Unmanned Systems
– Robot Orientation
ECB100 3 axis compass widely used in Laser Rangefinders
A laser rangefinder is a rangefinder that uses a laser beam to determine the distance to an object. The most common form of laser rangefinder operates on the time-of-flight principle by sending a laser pulse in a narrow beam towards the object and measuring the time taken by the pulse to be reflected off the target and returned to the sender. To get better performance, the laser rangefinders usually have internal GPS, compass and inclinometer.
SkyMEMS ECB100 3 axis compass is very small size, and it is easily integrated into the laser rangefinder. It enjoys high accuracy in direction and pitch and roll, and it has hard and soft magnetic compensation, and it has low power consumption, and can work in harsh environment. And ECB100 3 axis compass has been widely applied in different types of laser rangefinders, now tens of thousands of laser rangefinders are using SkyMEMS’s electronic compass sensors.
ECB100 3 axis compass widely used in antenna positioning
ECB100 3 axis compass is able to sense both direction and pitch and roll at high accuracy, which has hard and soft magnetic compensation, and it has low power consumption, and can work in harsh environment. Furthermore, ECB100 enjoys very small size and low cost, which is easily integrated into the antenna system, it has been widely used in antenna positioning applications.
ECB100 3 axis compass widely used in Buoy
The buoy’s sensors included two types: for air and water temperature, an anemometer for wind speed and direction and an electronic compass within the buoy to compensate for the effects of buoy rotation on wind direction.
ECB100 electronic compass sensor is used to provide the real-time position of the wave buoy. ECB100 electronic compass sensor uses magnetic sensors with wide dynamic range and ideal linearity, it enjoys the high accuracy and reliability with compact size, which is easy to be integrated into the systems, it has been widely selected by buoy applications.
Product Advantages
Why Selecting ECB100 3 axis compass?
ECB100 3 axis compass is designed and produced by SkyMEMS, it enjoys ultra-miniature size, high performance and accuracy, and high reliability. It is a popular electronic compass sensor in the market, which has the main following advantages:
High Accuracy, High Performance and Powerful Functions
ECB100 3 axis compass is designed and produced by SkyMEMS, it enjoys excellent technical advantages:
– Pitch and Roll Accuracy: ±0.1° (25°C, Full Range)
– Hard/Soft Magnetic Compensation, Tilt Compensation
– Support User Calibration
– Power Supply: 3.3±0.3VDC, Interface: LV-TTL
– Widely Working Temperature: -40~+85°C
ECB100 3 axis compass adopts big brand components, advanced production craft, fully calibrated, advanced SkyMEMS algorithm, which assured that our products have real actual precise and perfect performance.
Aerospace Level Reliability, 12-step Strictest Quality Control
We have advanced product test team and measurement equipment, and we cherish the quality as the life of the company, all our products must pass the strictest quality control procedures, our unique 12-step quality control assures our products enjoy top level quality.
Competitive Price, ODM supported
With strict cost control and massive production, we can provide the most competitive cost-effective prices, and we have abundant ODM service experience for customers around the world, that is why we can build up long term win-win cooperation with our customers.
Successful Applications in 10+ Fields, 1000+ Customers are Using
We are continuously focusing on MEMS measurement & control technologies, and have developed the most advanced and reliable 3D electronic compass sensor ECB100. and ECB100 has been widely used in laser rangefinders, antenna positioning, buoy, unmanned systems and marine navigation fields, etc. and now more than 1000 customers are using our electronic compass around the world.
World-class Production Line, Fast Delivery
We have the world class production line to assure that the production procedures are scientific, precise and normative, which also can assure our products to be fast delivered.
Service with Heart, Professional Technical Support
We have the professional technical support engineer team, which can provide 24-hour technical support and excellent after-sale service.
Serving customers with heart is the principle of SkyMEMS, Customer demand is the fundamental driving force of our development.
We treat our customers with heart, customers’ satisfaction is the direction and target of SkyMEMS. Through continuously technology innovation and service upgrading, we will realize win-win cooperation with customers.
FAQ
Q: when there are any types of magnetic forces e.g. metal objects, electronics, motors etc. the electronic magnetic compass performance is typically not very good. Do your electronic compasses have the ability to work in this type of environment?
A: for your concerned about electronic compass used in the magnetic interference, this is actually a normal phenomenon for electronic compass, cause these electronic compasses are made of magnetometer sensors, which will be influenced by the surrounding magnetic field
to solve this problem, we usually suggest our customer to adopt anti-interference electronic compass (like our EC2000 electronic compass, or select ECB100 with anti-interference casing), and install the electronic compass at least 20~30cm away from the magnetic forces e.g. metal objects, electronics, motors etc. (for motors, it is better 40cm away)
and at the same time, the second magnetic calibration should be executed after the ECB100 is installed, which can compensate the magnetic interference. cause the magnetic interference is very complicated, it depends on many aspects: such as installation position, second calibration
but we are very confident to say that our ECB100 electronic compass performs better performance, it has been qualified by Chinese military and hundreds of customers around the world. It enjoys high anti-interference, better performance.
Q: Is the 0.8° heading precision constant or does it have regular spike ( derivation ) and if yes, what is the actual value of these spikes?
A: for ECB100 accuracy, 0.8° RMS 25°C, tilt angle<30°, this accuracy doesn’t have regular spike, it is less than 0.8°
Q: What is the require calibration sequence after each boot?
A: cause the magnetic interference of the application environment is different, so installing the ECB100 electronic compass module, it needs to do the user calibration for the first time, and ECB100 supports local calibration, the calibration method please refers to the manual of user calibration.
Q: What is the protocol used to communicate with the board?
A: ECB100 uses LV-TTL interface, if you want to use RS232 or RS485 communication interface, we recommend u to use our ECB300 or EC2000.
Q: If we wanted to perform the user calibration through a microcontroller (in an embedded system housed inside our autonomous mini robot) so that we don’t have to connect a PC/laptop to it every time we need to calibrate the compass. So, do you have any software development kit (SDK) or API that can be used to replicate the electronic compass user calibration software in a certain programming language e.g. C/C++ for a microcontroller? That will significantly help us to perform on-site calibration on the robot without having to connect a PC externally to it.?
A: For your system, you can send the commands to do the self-calibration, you can let your system to do the calibration through sending commands, about the method please contact with us, we will provide the details. And we also can provide the dynamic database, dll, which can be used in win10, 64bit OS system. Which is really convenient for your applications.
Q: What is the main difference between ECB100 and ECB200?
A: ECB100 is smaller than that of ECB200, while ECB200’s accuracy is higher than that of ECB100, and both ECB100 and ECB200 adopts LV-TTL interface, both are board-based, and small size, and easy to be integrated into your system, ECB100 is a little cheaper than that of ECB200.
Q: How about the delivery time?
A: for our standard model, if we have them in stock, only need 2~3days to re-test before shipping, if it is out of stock, then need around 2 weeks to arrange the production and tests. For the ODM electronic product, if needing to modify the structure, it will need around 3~4 weeks to arrange the production and tests.
Q: How to arrange the payment?
A: about the payment, please pay to our company account, the beneficiary’s name: NANJING SKY MEMS TECHNOLOGY CO., LTD. And our email is only @skymems.com to contact with u formally. To notice this to avoid the loss.
